Induction Heating Vacuum Press

Induction Heating Vacuum Press

High-Performance Molding for Advanced Thermoplastics

The Induction Heating Vacuum Press by High Gain is a precision-engineered solution specifically designed for the research and high-end production of advanced thermoplastic composite materials. Engineered to handle the rigorous thermal and pressure requirements of modern polymers, this equipment is essential for manufacturing high-performance components using carbon fiber, ceramic, and diamond composite materials.

Key Technical Capabilities

Extreme Thermal Range: Operates at temperatures up to 450°C, making it compatible with high-performance polymers such as PEEK, PEKK, PPS, and PI.

Rapid Induction Heating: Utilizing electromagnetic induction, the system can reach target temperatures in as little as 20 minutes, significantly reducing cycle times for thermoplastic unidirectional (UD) prepregs.

Precision Pressure Control: Features a 25-segment intelligent pressure system with a control tolerance of +/-0.01MPa.

Superior Parallelism: Maintains a parallelism of up to +/-0.03mm, ensuring uniform thickness and structural integrity across the entire part.

Advanced Features & System Design

Intelligent PLC Control: Provides fully automated, multi-stage heating and pressurization cycles. The system stores comprehensive data for process analysis and full traceability.

Optimized Cooling: Equipped with a circulating water-cooling system using an oil-water separation heat exchange method, allowing for controlled cooling rates of 1–15°C/Min.

High-Quality Construction: Built with specialized Japanese high-temperature steel plates to withstand repeated thermal cycling without deformation.

Servo-Driven Hydraulics: The servo system provides faster, more accurate pressurization with automated fast/slow mold closing speeds.

Optional Vacuum Integration: Can be configured with a vacuum device to eliminate volatiles and porosity, drastically improving the quality of the final composite part.

Specifications Table

Targeted Industrial Applications

This press is ideally suited for industries requiring lightweight, high-strength thermoplastic components, including:

Aerospace & Defense: Primary and secondary structural components.

Automotive: High-cycle production of carbon fiber reinforced parts.

Electronics & Medical: Precision molding of specialty polymers like PEEK and PPS.

Railway & Marine: Large-scale durable composite structures.
